North America NISPT-2 16/2 16AWG 2C
|
Bulk Power Cord Wire: North America NISPT-2 16/2 16AWG 2C NISPT-2 bulk power cord wire for use in the USA and Canada. Our NISPT-2 16 gauge bulk flexible cable is the same as SPT-2 two conductor wire except it is double insulated for better reduction of interference. The NISPT-2 16/2 product is commonly used for small appliances, TVs, radios and light duty products that only use two conductor power cords. The difference between NISPT-2 and SPT-2 is that the NISPT-2 wire is double insulated. The individual conductors have jackets and then those are covered with an outer jacket. With SPT-2, the conductors are contained in the outer jacket only with no inside insulation. This 16 gauge 2 conductor NISPT-2 power cord wire is sold by the foot on 36" or 24" wooden spools. For price, availability or consultation contact us at: Phone: 888-788-4884 Email: sales@signalandpower.com |
| Attribute | Specification |
|---|---|
| Country Category | North America |
| Voltage | 300V |
| Amperage | (under 50ft long) 13 amps |
| Cord Length | Bulk |
| Wire Jacket Standard | NISPT-2 |
| Gauge | 16AWG |
| Conductors | 2 |
| Copper Wire Stranding | 65 strands of 0.16mm² wire |
| Conductors Material | Stranded and Annealed bare Copper |
| Conductor Insulation Material | PVC |
| Jacket Material | PVC |
| Jacket Temp. Rating | 105°C |
| Wire Outer Diameter | 4.1mm by 7.9mm |
| Conductor Color Code | NACC (black, white) |
| 36 inch Spool Maximum Quantity | 27,880 feet |
| 24 inch Spool Maximum Quantity | 6,970 feet |
| Certifications | cUL, CSA |
| Environmental Compliance | RoHS, REACH, Sony Green Partner, ISO14001:2015, ISO9001:2015 |
| Country of Origin | China |
