8.2' Power Cord

BS1363 to C15

P-6120-082B BLK QTY

Regular price $10.46 Save $-10.46
333 in stock
Shop Wholesale / Login

P-6120-082B

BS1363 plug to IEC C15 2.5 meter (8.2 feet) power cable with H05V2V2-F 1.0mm² black wire and all appropriate approvals including ASTA, HKSI, PSB Spring, MS SIRIM, SASO, and GMark. This BS1363 to C15 power cord is also referred to as the BS1363 to C15 mains power lead or BS1363 to C15 mains cable.

Attribute Specification
Male Plug BS1363 with 10A fuse 3 prong
Female Receptacle IEC60320 C15 3 prong 10A
Wire Jacket Standard H05V2V2-F
Gauge 1.0mm²
Conductors 3 wire
Copper Wire Stranding 32 strands of 0.202mm²
Jacket Material PVC
Temperature Rating Up to 90°C
Wire Outer Diameter 7.0mm
Conductor Color Code Blue, Brown and Green with Yellow stripe / ICC (International color code)
Voltage Up to 250 Volts AC
Amperage Up to 10 Amps
Color Black
Number Per Carton 50
Carton Weight 34.4 lbs (15.6kg)
Carton Dimensions

15.75 X 11.8 X 9 inches (40 X 30 X 23cm)

Testing 100% are individually tested for Hi-Pot (dielectric voltage withstand test), opens, shorts and pinout.
Certifications UK ASTA, Singapore PSB, Hong Kong HKSI, Malaysia MS SIRIM, Saudi Arabia SASO, Gulf Countries GMark
Environmental Compliance RoHS, REACH, Sony Green Partner, ISO14001:2015, ISO9001:2015
Country of Origin China
